Windows 10 – SCCM Language Pack Integration

I’ve tried so many different ways to deploy Windows 10 clients in different languages and there was only one way working for me, I like to share with you. Our aim was to deploy Windows 10 clients in 28 different languages, so our itention was to deploy these clients in English and to deploy the language packs afterwards. We didn’t want a client with 27 language packs installed that must be maintained with every Windows 10 Feature Update. But we got a lot of Problems with the Windows 10 UI that sometimes didn’t changed the language as exspected or the time and date formats were set comletelly wrong. The only way I figured out was to deploy language packs by the following order.

Install the language pack during the OS installation using the dism command dism.exe /norestart /online /add-package /packagepath:.\lp.cab
Restart the computer
Run a script executing the following command C:\Windows\System32\control.exe intl.cpl /f:”configuartion.xml”
Restart the computer

Step 3 is neccessary to set the installed language pack as activated and to install the corresponding “Input Preferences”.

Create Package – “MS W10 1703 LanguagePack de-DE”

Lets start with building a deployment package including the german languagepack *.cab file, a PowerShell script for setup and *.xml file that is needed for configuration.

Quick Tip – SCCM 1706 – “Machine does not meet OSD capture requirements. Capture cannot continue.”

Problem

During a Build and Capture Task Sequence I ran into the following error “Machine does not meet OSD capture requirements. Capture cannot continue.”

PowerShell – How to build a GUI with Visual Studio

Sometimes PowerShell scripts are a way to comlicated to present your hardly gathered data to end users that are not familiar with the command line. Therefore I recommend to present data by Windows WPF forms that could be achived without being a coding expert.

With the help of Visual Studio everyone is able to build WPF forms even without coding expertise. In this tutorial I will show you how to generate a User Information script displaying Hostname, Username and Domainname. This is a basic tutorial showing how to build a graphical user interface within minutes. The script can be extended easily, for example you can display “Model Type” of your Hardware, “Network Drives” connected, “Outlook Profile” size, installed software and a lot more!

Visual Studio can be downloaded for free at Microsoft – https://www.visualstudio.com/downloads/

Start a Project

Start Visual Studio (Express / Community / Professional) and open a “New Project …”

Select “WPF Appplication” and confirm with “OK“.
